Freezer High Speed Door

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
Freezer high speed door, also known as a high-speed freezer door or a cold storage high-speed door, is a specialized type of industrial door designed for use in cold storage and freezer environments. These doors are essential for maintaining temperature control, preserving the cold chain, and ensuring the efficient operation of cold storage facilities.As a China industrial door manufacturer, we have a cost advantage
  • Starting from US $1259/set

Color:
Hood cover box material :
Safety Airbag:
Pedestrian-vehicle segregation radar:
Availability:

Technical Data

Max dimension
width * height 3500mm*4000mm
Power supply
220±10%V 50/60Hz
Output power 0.75-1.5KW
Normal speed
open1.2m/s close 0.6m/s
Max speed
open 2.0m/s close 1.0m/s
Opening frequency
1000 times /day
Wind resistance
28m/s (Class 10)
Air tightness
leakage through the door is 95m³/hour under 30 pa pressure

Product Details

Curtain
The curtain of the cold storage fast door is made of PVC cloth with interlayer, which has a good effect of heat preservation and insulation.

PVC sandwich fabric: double skin is 0.8mm PVC fabric, and inside is filled with high density insulating rock wool, total thickness is 20mm.

Auto-reset design

The curtain and track connection of the freezer high speed roll up door is designed with zipper.

Use zipper to connect the fabric with frame side guide rail as a whole body, realizing better sealing performance and air-tightness.

And when there is accident collision, the fabric can get out from guide rail and return automatically, this reduces daily maintenance.

Anti-Freezing Heating Design

Cold storage fast roller shutter doors are usually used in environments with low temperatures. To prevent the door from freezing and becoming inoperable, we install heating coils for it.

This can avoid damage for fabric and driving system when the door is frozen steadily in low temperature room.

Frame and Rails

Two guide rails, which includes one top cover and one motor cover included.

Thickness:1.5mm for guide rail,1.0mm for cover box.

Standard material: Galvanized steel, surface is painted.

Optional material: 304 stainless steel or aluminum alloy.

Motor and Controller

Our cold room rapid doors use Italian leading servo technology motors with guaranteed quality.

Absolute encoder+inbuilt incremental encoder,double encoder ensure low failure rate.

Safety devices

We equip our cold storage quick doors with a number of safety devices, in order to maximize the safety of the door during operation and reduce the accident rate.

Photocell sensor:When there is a human or vehicle under the door,the door will stop closing and get up automatically.

This will avoid accident collisions.

Safety bottom edge

When the bottom bar of the door touches something,it will stop closing immediately and get up automatically.

Alarm light and emergency buttons

Alarm lights and emergency buttons are critical safety features for high-speed doors. The alarm light serves as a visual warning, alerting individuals to the door's operation and ensuring they stay clear of the moving door. This feature is especially useful in busy industrial environments where noise levels can be high, and visual signals are more effective.

Emergency buttons provide an immediate way to stop the door's operation in case of an emergency. Located conveniently near the door, these buttons allow for quick and easy access to halt the door's movement, preventing accidents and ensuring the safety of all personnel in the vicinity.

Open methods

Freezer rapid roll up doors usually offer five different methods for opening, allowing you to choose the one that best suits your operational needs:


Vehicle Loop Detector:

This method automatically opens the door when a vehicle approaches, ensuring seamless entry and exit for transport vehicles without manual intervention.


Radar Sensor:

Ideal for busy areas, the radar sensor detects motion and opens the door, providing a touchless and efficient solution for high-traffic zones.


Push Button:

A simple and reliable method, the push button allows manual control over the door, suitable for situations where precision timing is crucial.


Pull Switch:

The pull switch offers a straightforward and accessible way to open the door, often used in industrial settings where ease of use is paramount.


Remote Control:

For ultimate convenience, the remote control enables the door to be opened from a distance, perfect for environments where mobility is necessary.

Each of these options enhances the functionality of freezer fast roller shutter doors, catering to diverse operational requirements and ensuring optimal performance in various settings.

Advantages


Temperature Control


The insulation and sealing mechanisms of freezer high speed roll up doors maintain consistent temperatures in cold storage areas, ensuring product quality and compliance with temperature-sensitive regulations.

Energy Efficiency


The rapid operation of these doors reduces energy consumption by minimizing the escape of cold air and preventing temperature fluctuations. This results in lower energy costs.

Quick Access


High speed operation allows for efficient and rapid access for personnel and equipment, improving workflow and reducing waiting times.

Safety


Safety features such as motion sensors and emergency opening systems enhance the safety of personnel working in the cold storage area, reducing the risk of accidents and injuries.

Durability


The freezer high speed doors are built to withstand the harsh conditions of freezer environments, ensuring a long service life and reducing the need for frequent repairs or replacements.

Compliance


Cold room rapid doors help facilities comply with food safety regulations, quality control standards, and other industry requirements.
